Roland UP/DOWN/CROSS Scan Converter

Roland's new video converters address the demand for high-quality, lossless video and audio converters for live/post-production as well as installed systems. They include the Roland VC-1-HS (HDMI to SDI), VC-1-SH (SDI to HDMI), VC-1-DL (Bi-directional SDI/HDMI with audio/video delay and frame sync) and VC-1-SC (Up/Down/Cross Scan Converter to/from SDI/HDMI).

The VC-1 Video Converter series

The VC-1 Video Converter series provides uncompromising picture quality by maintaining the video characteristics of the original signal. There are no interlacing artifacts or other conversion or signal errors sometimes found with other video converters. The VC-1 series also features an on-board re-clocker to compensate for attenuation of SDI signals carried over long distances. The VC-1 series also supports both level A and B 3G-SDI, letting you connect a variety of higher quality SDI sources. The VC-1-SC also enables input from analog sources such as RGB and component along with built-in scaler.

The VC-1 series is HDCP compliant allowing you to convert or pass-through HDCP signals with the exception of any SDI output. The selectable audio embedding or de-embedding lets you route different audio sources to or from video devices.

Features:

3G (Level A&B) /HD/ SD SDI

HDMI In/Out

RGB/Component In

Composite In

HDCP Support

Built-in Frame Synchronizer and Scaler

Audio Embedding or De-Embedding

VC-1 RCS, PC/MAC Control Application

Up/Down/Cross, Frame Rate, I/P, and Aspect Ratio Conversion
