Product Description
-
Choice of Fast Ethernet and Gigabit Ethernet connectivity
-
Energy-efficient technology for power savings
-
PoE power auto-balance - the switch automatically balances the PoE power based on the device needs independent of PoE class detected, at a very granular level
-
Auto-MDI/MDIX eliminates the need for crossover cables
-
Non-blocking switching architecture for Maximum throughput at wire speed
-
Auto-negotiation for automatic connection at the highest common speed between switch and an end device
-
Desktop or rack mountable
-
Power-Over-Ethernet (PoE) and PoE options available for powering IP Security Cameras, VoIP phones, wireless access points, and other PoE-powered devices
-
These PoE Switches are not just flexible in terms of placement they are also flexible in terms of PoE power
-
Built-in PoE power selector switch that allow for optional / interchangeable power adapters (sold separately) that can be used to increase (or decrease) the PoE power available on the switch
-
The flexible mounting system gives you the flexibility to place them in a desktop environment, wall mount them, or even rack-mount (accessories included)
-
Plug And Play
-
Simple setup with no software or configuration needed
-
Power-Over-Ethernet
-
16 PoE ports with 183W total power budget, and includes NETGEAR FlexPoE allowing to reduce the power budget to 155W or even 76W (w/separately purchased power supply modules)
-
Flexible Mounting
-
Mount on rack, desktop, or wall
-
Small Size, Metal Case And Silent Operation
-
Durable quality, space saver, and quietness for peace of mind
-
Sturdy Metal Case, Desktop/Rackmount Form Factor With Quiet Fans
-
Can be placed on desk or on mounted rack and will operate quietly with assured durability
Product Specification
| Brand | Netgear |
| Product Type | POE Switch |
| Product Model | GS116PP |
| Gigabit Ethernet RJ-45 Copper Ports | 16 |
| PoE/PoE Ports | 16 PoE (183W PoE budget) |
| Power Supply | External Input 54V 3.7A (200W) |
| Power Supply Supported | External |
| Form Factor | Desktop/Rackmount/Wall-Mount |
| Product Specifications | |
| Gigabit Ports | 16 |
| Maximum MAC Entries | 4K |
| Buffer Size | 1MB |
| Energy Efficient Enthernet (IEEE 802.3az Complaint) | Yes |
| PoE Support | |
| 802.3AF | Ports 1-16 |
| 802.3AT | Ports 1-16 |
| PoE Maximum Power Per Port | Up to 15.4w for 802.3af and 30W for 802.3at |
| Total PoE Power Budget | 183W |
| Forwarding Modes | Store-and-forward |
| Bandwidth | 32Gbps |
| Jumbo Frame Support | Yes |
| Mean Time Between Failures (MTBF) | 2,088,514 hours |
| LEDs | |
| Per Port | Speed, Link, Activity, PoE |
| Per Device | Power Status, PoE Maximum |
| Power Consumption | |
| Power Supply | External Input 54V 3.7A (200W) |
| Power Supply Supported | External |
| Maximum Power (Worst Case, All Ports Used, | 200W |
| Min Power (Link-Down Standby) (Watts) | 2.68W |
| Heat Dissipation (Maximum And Min) (BTU/hr) | 680.58 BTU/9.14 BTU |
| Energy Efficient Ethernet (EEE) IEEE 802.3az | Yes |
| Short Cable Power Reduction | Yes |
| Auto Power-Down | Yes |
| Operating Temperature | 0° to 50°C (32° to 122°F) |
| Humidity | 90% Maximum relative humidity (RH), non-condensing |
| Altitude | 10,000 ft (3,000 m) Maximum |
|
$
