Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Alternate Mfr Part Number | BES 516-325-E5-C-S4 |
| Body Style | Cylindrical |
| Connection Type | M12 3-Pin |
| Current, Switching | 200 mA |
| Frequency, Switching | 5 kHz |
| Housing Material | Brass |
| IP Rating | IP68 |
| Maximum Operating Temperature | 70 C |
| Measurement Range | 2 mm |
| Minimum Operating Temperature | -25 C |
| Mounting Type | M12 Threaded Flush |
| Operating Temperature, Maximum | 70 C |
| Operating Temperature, Minimum | -25 C |
| Output | PNP-NO |
| Primary Type | Inductive Proximity Sensors |
| Series | |
| Shielding | Shielded |
| Supply Voltage | 10-30 VDC |
| Termination | 3-wire |
Overview
Our standard inductive sensors are ideal for object detection in metal areas. Here, they are suitable for a multitude of applications.
Because they work without contact, they are wear-free and very resistant to dirt. The sensors are also short-circuit-proof. We provide the inductive standard sensors in configurations from Φ 3 mm to 80 × 80 mm square dimensions.
